Article number |
Nominal power |
Color Temperature(CCT) |
Delivered lumens |
Beam angle |
Finish |
|
L-P438-COB4-30K-25
|
L-P438-COB4-30K-25
|
15W
|
3000K
|
975lm
|
25°
|
White/Black
|
L-P438-COB4-30K-25
CYLINDER-CEILING, with LED, system power: 15W, luminous flux of luminaire 970lm. colour rendering index CRl≥90, colour temperature 3000K, warm white, lifetime LED 50'000h, Photobiological safety: Safe, 220V, rated current: 350mA, Beam angle: 25°, black/white, ON/OFF | DALI. ingress protection IP65. Ø=80 mm, H=125 mm
Color Consistency SDCM
SDCM3
Ingress Protection (IP)
IP65
Color Temperature(CCT)
3000K
Color Rendering Index(CRI)
CRI≥90
Unified Glare Rating (UGR)
UGR<16
Light Control
ON/OFF | DALI
|
|
L-P438-COB4-30K-38
|
L-P438-COB4-30K-38
|
15W
|
3000K
|
975lm
|
38°
|
White/Black
|
L-P438-COB4-30K-38
CYLINDER-CEILING, with LED, system power: 15W, luminous flux of luminaire 970lm. colour rendering index CRl≥90, colour temperature 3000K, warm white, lifetime LED 50'000h, Photobiological safety: Safe, 220V, rated current: 350mA, Beam angle: 38°, black/white, ON/OFF | DALI. ingress protection IP65. Ø=80 mm, H=125 mm
Color Consistency SDCM
SDCM3
Ingress Protection (IP)
IP65
Color Temperature(CCT)
3000K
Color Rendering Index(CRI)
CRI≥90
Unified Glare Rating (UGR)
UGR<16
Light Control
ON/OFF | DALI
|
|
L-P438-COB4-30K-24
|
L-P438-COB4-30K-24
|
25W
|
3000K
|
1700lm
|
24°
|
White/Black
|
L-P438-COB4-30K-24
CYLINDER-CEILING, with LED, system power: 25W, luminous flux of luminaire 1700lm. colour rendering index CRl≥90, colour temperature 3000K, warm white, lifetime LED 50'000h, Photobiological safety: Safe, 220V, rated current: 650mA, Beam angle: 24°, black/white, ON/OFF | DALI. ingress protection IP65. Ø=120 mm, H=150 mm
Color Consistency SDCM
SDCM3
Ingress Protection (IP)
IP65
Color Temperature(CCT)
3000K
Color Rendering Index(CRI)
CRI≥90
Unified Glare Rating (UGR)
UGR<16
Light Control
ON/OFF | DALI
|
|
L-P438-COB4-30K-38
|
L-P438-COB4-30K-38
|
25W
|
3000K
|
1700lm
|
38°
|
White/Black
|
L-P438-COB4-30K-38
CYLINDER-CEILING, with LED, system power: 25W, luminous flux of luminaire 1700lm. colour rendering index CRl≥90, colour temperature 3000K, warm white, lifetime LED 50'000h, Photobiological safety: Safe, 220V, rated current: 650mA, Beam angle: 38°, black/white, ON/OFF | DALI. ingress protection IP65. Ø=120 mm, H=150 mm
Color Consistency SDCM
SDCM3
Ingress Protection (IP)
IP65
Color Temperature(CCT)
3000K
Color Rendering Index(CRI)
CRI≥90
Unified Glare Rating (UGR)
UGR<16
Light Control
ON/OFF | DALI
|
|
L-P438-COB5-30K-24
|
L-P438-COB5-30K-24
|
40W
|
3000K
|
2920lm
|
24°
|
White/Black
|
L-P438-COB5-30K-24
CYLINDER-AIR, with LED, system power: 40W, luminous flux of luminaire 1920lm. colour rendering index CRl≥90, colour temperature 3000K, warm white, lifetime LED 50'000h, Photobiological safety: Safe, 220V, rated current: 1000mA, Beam angle: 24°, black/white color, ON/OFF | DALI. ingress protection IP65. Ø=150 mm, H=170 mm
Color Consistency SDCM
SDCM3
Ingress Protection (IP)
IP65
Color Temperature(CCT)
3000K
Color Rendering Index(CRI)
CRI≥90
Unified Glare Rating (UGR)
UGR<16
Light Control
ON/OFF | DALI
|
|
L-P438-COB5-30K-35
|
L-P438-COB5-30K-35
|
40W
|
3000K
|
2920lm
|
35°
|
White/Black
|
L-P438-COB5-30K-35
CYLINDER-AIR, with LED, system power: 40W, luminous flux of luminaire 1920lm. colour rendering index CRl≥90, colour temperature 3000K, warm white, lifetime LED 50'000h, Photobiological safety: Safe, 220V, rated current: 1000mA, Beam angle: 35°, black/white color, ON/OFF | DALI. ingress protection IP65. Ø=150 mm, H=170 mm
Color Consistency SDCM
SDCM3
Ingress Protection (IP)
IP65
Color Temperature(CCT)
3000K
Color Rendering Index(CRI)
CRI≥90
Unified Glare Rating (UGR)
UGR<16
Light Control
ON/OFF | DALI
|
